Waterless Scent Diffusers
Portable Waterless Scent Diffuser HH-D01
HH-D01 is a portable waterless scent diffuser with cold diffusion technology, a rechargeable battery and an oil capacity of up to 10mL. Select logo, color and packaging customization for your brand or wholesale project.
- Waterless cold diffusion
- Rechargeable 1200mAh battery
- USB-C 5V/1A charging
- Selectable mist duration and pause interval
- Model
- HH-D01
- Diffusion Method
- Waterless / Cold Diffusion
- Oil Capacity
- ≤10mL
- Battery Capacity
- 1200mAh / 3.7V / 4.44Wh
- Charging Input
- USB-C 5V/1A
- Material
- Metal + Polypropylene
OEM / ODM options include custom logo, color and packaging, with fragrance pairing and private label project support.
Product Overview
Develop a home fragrance collection around a compact, rechargeable aroma diffuser. HH-D01 combines waterless cold diffusion with selectable mist and pause settings. Pair the device with a compatible fragrance oil and a private label presentation for your market.
Waterless Cold Diffusion Technology
HH-D01 uses waterless cold diffusion with compatible fragrance or aroma oil. Select an oil suited to this device; a fragrance designed for reed diffusers or massage is not interchangeable with a compatible diffusion oil.
Compact & Rechargeable Design
A rechargeable 1200mAh / 3.7V / 4.44Wh battery supports portable use. USB-C charging accepts 5V/1A input. Black and white finishes suit different brand collections.
Adjustable Mist & Timer Settings
Select the mist duration and pause interval for your application.
- Mist duration: 5s / 15s / 30s
- Pause interval: 60s / 180s / 360s
Applications
Fragrance Oil Compatibility
Compatible
- Low-viscosity fragrance / aroma oils
- Compatible blended oils
Avoid / Not Recommended
- High-viscosity oils
- Oils with sediment
- Massage oils
- Reed diffuser oils
Product Design Details
Nozzle design
Black finish
Product Specifications
| Model | HH-D01 |
|---|---|
| Product Type | Portable Waterless Scent Diffuser |
| Diffusion Method | Waterless / Cold Diffusion |
| Oil Capacity | ≤10mL |
| Battery Capacity | 1200mAh / 3.7V / 4.44Wh |
| Charging Input | USB-C 5V/1A |
| Material | Metal + Polypropylene |
| Mist Duration | 5s / 15s / 30s |
| Pause Interval | 60s / 180s / 360s |
| OEM/ODM | Logo, color, packaging, fragrance pairing and private label customization |
| Power | 5W |
| Control | Touch switch |
HH-D01 Product Gallery
Product Videos
How to Use
- Keep the device upright on a stable surface. Turn it off before changing oil; do not tilt or invert it with oil inside.
- Turn the nozzle counterclockwise and pull out the oil bottle. Unscrew the bottle to fill or replace it with compatible oil.
- Align the marked holes on the body and nozzle, press the nozzle down, and turn it clockwise to secure it.
- Press and hold the right button for two seconds to switch on. Briefly press the left button for mist duration and the right button for pause interval.
- Press and hold the right button for two to three seconds to switch off. The charging indicator is red during charging and green when fully charged.
Packaging & Private Label
Color box: 232 × 139 × 92 mm. Master carton: 24 pieces; 48 × 33 × 40 cm. Gross weight: 10.8 kg/carton; net weight: 9 kg/carton. Container loading: 10,584 pieces per 20GP and 21,960 pieces per 40GP. Logo, color and packaging customization are available for private-label projects.
Explore packaging customization → Quality & Manufacturing Planning
Include your required inspection criteria, packaging artwork and target-market documentation in the OEM brief. Review these requirements alongside your sample before placing a production order.
Explore our factory →Purchasing FAQ
Is the HH-D01 a waterless scent diffuser?
Yes. HH-D01 uses waterless cold diffusion with compatible fragrance or aroma oils.
What size fragrance oil bottle does it use?
The confirmed oil capacity is up to 10mL.
Can I use essential oils in this diffuser?
Oil compatibility depends on the formulation. Choose low-viscosity fragrance or aroma oils and compatible blended oils. Avoid high-viscosity oils, oils with sediment, massage oils and reed diffuser oils. Share the specific oil with us for compatibility review before use.
Does the diffuser need to stay plugged in?
HH-D01 has a rechargeable 1200mAh battery for portable use and charges through USB-C at 5V/1A. No battery runtime is specified here.
Can I customize the diffuser with my brand?
Yes. OEM / ODM project options include your logo, color, packaging, fragrance pairing and private label presentation. Share your quantity and branding brief for a quotation.
Where can HH-D01 be used?
Applications include homes, offices, hotels, meeting rooms and retail or brand stores. Share your space and intended scenting use when requesting samples.
Looking for a Private Label Waterless Scent Diffuser?
Tell us about your project. Share your market, estimated quantity, customization needs and whether you would like fragrance oils with your diffuser.
